The Dell EMC PowerEdge R450, with 3rd generation Intel® Xeon® Scalable processors, offers exceptional value and density with excellent performance.Buy DELL Poweredge R450 Server from Promise Computer Technology – DELL Authorized Partner in Dubai.
The Dell™ PowerEdge™ R450 is Dell’s latest 2-socket, 1 U rack servers designed to run complex workloads using highly scalable memory, I/O, and network options. The systems feature 3rd Generation Intel® Xeon® Processor Scalable Family , up to 16 DIMMs, PCI Express® (PCIe) 4.0 enabled expansion slots, and a choice of network interface technologies to cover NIC. The R450 is a general-purpose platform capable of handling demanding workloads and applications, such as data warehouses,ecommerce, databases, and high-performance computing (HPC).
Front View
1.
Left control panel
2.
Drive(optional)
3.
VGA port
4.
Right control panel
5.
Information tag
6.
Drive blank
Rear View
1.
PCIe expansion card riser 1
2.
BOSS riser
3.
PCIe expansion card riser 2c
4.
Power supply unit (PSU 1)
5.
Power supply unit (PSU2)
6.
System identification button
7.
VGA port
8.
OCP NIC port
9.
USB 3.0 port
10.
USB 2.0 port
11.
iDRAC dedicated port
12.
NIC ports
Dell EMC PowerEdge R450 - PER450-16-600
Dell EMC PowerEdge R450 - PER4502A-232-PS
Processor
Intel Xeon Silver 4310
Intel Xeon 4309Y
Memory
16 GB
16 GB
Storage
600 GB
1.2 TB
Storage Controller
PERC H755 Controller
PERC H755 Controller
Network Controller
Broadcom 5720 Dual Port 1Gb On-Board LOM
Broadcom 5720 Dual Port 1 Gb On-Board LOM
Power Supply
600 W
800 W
Form Factor
1 U
1 U
Dimensions
42.8 x 482 x 748.79 cm
42.8 x 482 x 748.79 cm
Weight
18.62 kg
18.62 kg
Dell PowerEdge R450 - Features
Increase efficiency and accelerate operations with autonomous compute
The Dell EMC Open Manage systems management portfolio tames the complexity of managing and securing IT infrastructure. Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell EMC OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, andprotect your technology environment.
Built-in proactive resilience through a complete portfolio of solutions
From the silicon and supply chain all the way to asset retirement, know that your servers are safe and secure with innovative Dell EMC and Intel technologies. We give you the confidence of cyber resilience with enterprise class security that minimizes risk for any organization, from small business to hyperscale
Up to two 3rd Generation Intel Xeon Scalable processors, with up to 24 cores per processor
Memory
Memory 16 DDR4 DIMM slots, supports RDIMM max 1 TB, speeds up to 2933 MT/s
Storage controllers
•Internal controllers (RAID): PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150 •Internal Boot: Internal Dual SD Module or Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2x M.2 SSDs or USB •External PERC (RAID): PERC H840 •External HBA (non-RAID) HBA355e
Drive Bays
Front bays: •Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB •Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 61.4 TB
Power Supplies
•600W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant •800W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant •1100W -48Vdc hot swap redundant (CAUTION: only works with -48Vdc to -60Vdc power input)
Cooling options
Air cooling
Fans
• Standard (STD) fans or High performance SLVR fansn • Up to seven cold swap fans
Dimensions
•Height – 42.8 mm (1.7 inches) •Width – 482 mm (18.97 inches) •Depth – 734.95 mm (28.92 inches) – without bezel, 748.79 mm (29.47 inches) – with bezel
Form Factor
1U rack server
Embedded Management
•iDRAC9 •iDRAC Direct •iDRAC RESTful API with Redfish •iDRAC Service Module •Quick Sync 2 wireless modulen
OpenManage Integrations •BMC Truesight •Microsoft System Center •Red Hat Ansible Modules •VMware vCenter and vRealize Operations Manager OpenManage Connections •IBM Tivoli Netcool/OMNIbusnIBM Tivoli Network Manager IP Edition •Micro Focus Operations ManagernNagios CorenNagios XI
Security
•Cryptographically signed firmwarenSecure BootnSecure Erase •Silicon Root of Trust •System Lockdown (requires iDRAC9 Enterprise or Datacenter) •TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Embedded NIC
2 x 1 GbE LOM
Network Options
1 x OCP 3.0
GPU Options
NA
Ports
Front Ports : •1 x Dedicated iDRAC Direct micro-USB •1 x USB 3.0 •1 x VGA Internal Ports: •1 x USB 3.0 (optional) Rear Ports: 1 x USB 2.0 •1 x Serial (optional) •1 x iDRAC ethernet port •1 x USB 3.0 •2 x Ethernet •1 x VGA
•Canonical Ubuntu Server LTS •Citrix Hypervisor •Microsoft Windows Server with Hyper-V •Red Hat Enterprise Linux •SUSE Linux Enterprise Server •VMware ESXi
OEM-ready version available
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.
