HPE ProLiant DL385 Gen10 Server

The HPE ProLiant DL385  Gen10 Server is redefining price/performance with the new math for virtualized compute. Powered by the latest AMD EPYC 7xx2 Series Processors, the HPE ProLiant DL385 Gen10 Server offers greater processing power and faster memory speeds up to 2933 MT/s. This 2P, 2U server has been designed with flexibility while delivering a high maximum core count and large memory footprint. Choose this purpose-built platform for virtualization.

HPE ProLiant DL385 Gen10 Server – Front View
1. Quick removal access panel 2. Drive Bay 1. Optional Universal Media bay. 2 USB 2.0 and Display port standard shown (8 SFF bay or 6 SFF+2NVMe or 8NVMe optional)
3. Optional Optical drive. Requires Universal Media bay 4. Optional 2 SFF HDD, requires optional Universal Media bay
5. Drive Bay 2. NVMe shown (8 SFF, 6SFF+ 2NVMe or 8 NVMe PCIe SSD optional) 6. Drive Bay 3. NVMe shown (8 SFF, 6SFF + 2NVMe or 8 NVMe PCIe SSD optional) 7. Power On/Standby button and system power LED button
8. Health LED 9. NIC status 10. UID button
11. iLO Front Service Port 12. USB 3.0 13. Serial label pull tag
14. Box 3 15. Box 2 16. Box 1
17. Optional front display port (Via Universal Media Bay) 18. Optional USB 2.0 (via Universal Media Bay)
1. Unit ID button 2. Health LED
3. NIC status 4. Power On/Standby button and system power LED button
HPE ProLiant DL385 Gen10 Server – Front View
5. Front display port 6. iLO Front Service Port 7. Serial label pull tag
8. Optional optical drive shown (blank as standard) 9. Optional 2 SFF Drive bay, 2 NVMe shown
HPE ProLiant DL385 Gen10 Server – Internal View
1. Fan cage shown with 6 standard Hot-plug fans (High Performance fans optional) 2. 2 Processors (heatsinks shown)
3. Optional HPE Smart Storage Battery (not shown) 4. DDR4 DIMM slots. Shown fully populated in 32 slots (16 per processor)
5. MicroSD card slot (Optional Dual Micro-SD option) 6. Chassis intrusion detection connector
7. Optional HPE Flexible Smart Array Controller (P408i-a shown) 8. (Under) Hot Plug redundant HPE Flexible Slot Power supplies 9. Connection for second (optional) riser (Requires second CPU)
10. Embedded 4 x 1Gbe NIC(if equipped) 11. Primary PCIe riser, standard (Optional double wide GPU riser) 12. Optional Flexible LOM slot
14. Embedded M.2 connectors
1. Primary Riser. PCI Slots (Slots 1-3 top to bottom, riser shipped standard, not shown) Optional 2 SFF rear drives 2. Secondary Riser. PCI Slots (Slots 4-6top to bottom, not shown, requires second riser card, and second processor). Optional 2 SFF rear drives
3. Optional serial port 4. Tertiary Riser (Slots 7 - 8 top to bottom, not shown). Optional rear 2 SFF HDD
HPE ProLiant DL385 Gen10 Server – Rear View
5. Power supply power connection. Bay 1 6. Power supply Power LED. Bay 1 7. HPE Flexible Slot Power Supply. Bay 1
8. Power supply Power connection Bay 2 9. Power supply Power LED Bay 2 10. HPE Flexible Slot Power Supply Bay 2
11. VGA connector 12. Embedded 4 x 1GbE Network Adapter( if equipped) 13. Dedicated iLO management port
14. USB connectors 3.0 (2) 15. Unit ID LED 16. Optional Flexible LOM ports (Shown: 4 x 1GbE)

HPE ProLiant DL385 Gen10 Server

What’s New
  • • We enhanced two popular SKUs to address our customers workload needs. P11747-B21, comes with the popular HPE Smart Array P408i-a SR Gen10 Controller providing storage performance our customers demand.
  • • Additionally, P11809-B21 comes with the HPE Flexible Slot 800W power supply. The new standard for most of our customer’s; allowing for richer configurations while still maintaining full redundancy.
  • • The AMD EPYC 7371 is a 16 core, 3.1 GHz CPU with max boost to 3.8 GHz Perfect for electronic design automation, high-frequency-trading w/enterprise infrastructure, transcoding, web serving and more.
  • • The AMD EPYC 7261 has 8 core and is 2.5 GHz with all core boost to 2.9 GHz. It also has double the L3 cache over the AMD EPYC 7251. Perfect for your low core count, high-frequency requirements.
  • • HPE ProLiant DL385 Gen10 now has multiple SAN Ready Node configurations, to provide you with the most flexible server options to build your Hyper-Converged Infrastructure.
Flexible Design

The ProLiant DL385 Gen10 server has an adaptable chassis, including the modular drive bays that can be configured with up to 30 SFF, up to 19 LFF or up to 24 NVMe drive options and support for up to 3 double wide and 6 single wide GPU options. HPE Smart Array S100i Software RAID ships standard for an embedded m.2 boot. In addition, the redesigned HPE Smart Array Essential and Performance RAID Controllers offer performance and flexibility for additional features including the ability to operate in both SAS and HBA mode. Choice of HPE FlexibleLOM or PCIe standup adapters which offer a choice of networking bandwidth (1GbE to 4 x 10GbE) and fabric makes it scalable for changing business needs. The ProLiant DL385 supports a wide range of operating systems making it suitable for most environments.

Automation

HPE iLO 5 monitors servers for ongoing management, service alerting, reporting and remote management to resolve issues quickly and keep your business running from anywhere in the world. HPE OneView is an automation engine that transforms compute, storage, and networking into software-defined infrastructure to automate tasks and speed business process implementations. HPE Info Sight provides built-in AI predicts problems before they happen, proactively resolves issues, and continually learns as it analyzes data—making every system smarter and more reliable. HPE iLO RESTful API feature provides iLO RESTful API extensions to Redfish allowing you to take full advantage of the wide range of value-added API features, and integrate easily with leading orchestration tools.

Security

Silicon Root of Trust is an immutable fingerprint in the iLO silicon. The silicon root of trust validates the lowest level firmware to BIOS and software to ensure a known good state. Tied into the silicon root of trust is the AMD Secure Processor, a dedicated security processor embedded in the AMD EPYC system on a chip (SoC). The security processor manages secure boot, memory encryption and secure virtualization. Run Time Firmware Validation validates the iLO and UEFI/BIOS firmware at runtime. Notification and automated recovery is executed on detection of compromised firmware. If system corruption has been detected Server System Restore will automatically alert iLO Amplifier Pack to initiate and manage the system recovery process, avoiding lasting damage to your business by quickly restoring firmware to the factory settings or the last known authenticated safe setting.

Optimization

HPE Right Mix Advisor provides data-driven guidance drives the ideal hybrid cloud mix for workloads allowing for intelligent planning speeding migrations from months to weeks and controlling the cost of migration. HPE Green Lake Flex Capacity provides pay-per-use IT consumption on-premises, with real-time tracking and metering of resource usage, so you have the capacity you need to deploy quickly, pay for the exact resources you consume, and avoid over provisioning. HPE Foundation Care helps when there is a hardware or software problem offering several response levels dependent on IT and business requirements. HPE Proactive Care is an integrated set of hardware and software support including an enhanced call experience with start to finish case management helping resolve incidents quickly and keeping IT reliable and stable. HPE Financial Services helps you transform to a digital business with financing option and trade-in opportunities that align to your business goals.

Processor type : AMD
Processor name : AMD EPYC 7000 Series
Processor family : 2nd Generation AMD EPYC 7000 Series
Processor number : Up to 2
Processor core available : 64 or 48 or 32 or 24 or 16 or 8, per processor, depending on model
Processor cache : 256 MB or 192 MB or 128 MB L3, per processor, depending on model
Processor speed : 3.4 GHz, maximum depending on processor
Power supply type : 2 Flexible Slot power supplies, maximum depending on model
Expansion slots : 8 maximum, for detailed descriptions reference the QuickSpecs
Maximum memory : 4.0 TB with 128 GB DDR4
Memory, standard : 4 TB with 32 x 128 GB RDIMMs
Memory slots : 32
Memory type : HPE DDR4 SmartMemory
Memory protection features : ECC
System fan features : Hot-plug redundant fans, standard
Network controller : Choice of optional OCP plus standup, depending on model
Storage controller : 1 HPE Smart Array P408i-a and/or 1 HPE Smart Array P816i-a and/or 1 HPE Smart Array E208i-a (depending on model) etc.
Product dimensions (metric) : 8.73 x 44.54 x 74.9 cm
Weight : 15.1 kg
Infrastructure management : HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses)
Warranty : 3/3/3 - Server Warranty includes three years of parts, three years of labor, three years of on-site support coverage.
Drive supported : 8 or 12 LFF SAS/SATA/SSD with 4 LFF rear drive optional and and 2SFF rear drive optional 8 or 24 SFF SAS/SATA/SSD with 4 SFF rear drive optional, 16 SFF NVMe Front bay
