SRT48BP

48 V

Lead-acid battery

Stand alone battery stack

3 – 5 Years

Rack-mounted with kit

APCRBC155 , APCRBC155J

0 – 40°C

43.2 x 8.5 x 53.6 cm

29.9 kg

2 Years repair or replace

Overview Features Specification Media Videos Reference

Overview

SRT48BP - APC Smart-UPS SRT 48V Battery Pack

Remove Battery Modules

Rack-Mount Installation

1 : Secure two brackets to the XLBP. Use three screws in each bracket.

2 : Rest the XLBP on the rail shelves. Slide the XLBP into the rack.

3 : Secure the XLBP to the rack. Use two screws in each bracket.

4 : Slide the left hand side battery module into the XLBP.

5 : Slide the right hand side battery module into the XLBP

6 : Secure the RBCs to the enclosure. Use three screws on each RBC.

7 : Connect the two XLBP connectors from the enclosure to the two RBCs.

8 : Install one XLBP bezel and one UPS bezel.

Install battery modules and bezels

1 : Slide the bottom side battery module into the XLBP

2 : Slide the top side battery module into the XLBP

3 : Secure the battery modules with the enclosure with 6 screws.

4 : Connect the two XLBP connectors from the enclosure to the two RBCs.

5 : Install one XLBP bezel and one UPS bezel

Features

Availability

Multiple battery pack configuration: Connect up to 10 battery packs for extended runtime applications.
Advanced battery management included: Embedded monitoring at the cell, module, and cabinet level provides a clear picture of battery runtime and health, with the added benefits of predictable, consistent runtime performance and stable cell health.

Specification

Model Name:	APC Smart-UPS SRT 48V 1kVA 1.5kVA Battery Pack
Battery Output Voltage:	48
Battery Volt-Amp-Hour Capacity:	594
Battery Type:	Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Battery mounting:	Stand alone battery stack
Battery mounting:	3 - 5
RBC Quantity:	2
Net Weight:	65.92 lbs (29.9 kg)
Maximum Height:	17.0 inches (432.0 mm)
Maximum Width:	3.35 inches (85.0 mm)
Color:	Black

Media

Videos

Reference

APC Smart-UPS SRT 48V – Datasheet
