The Over IP LCD KVM Switch series is designed to simplify and centralize server management by combining a high-performance KVM switch with an integrated LCD console. Built for modern datacenters and enterprise IT environments, this product line enables both local and remote administrators to securely access, monitor, and control multiple servers from a single, space-saving 1U console. By merging powerful Over IP connectivity with reliable multi-server management, these switches deliver a seamless solution for maintaining uptime, improving operational efficiency, and ensuring secure access across your entire IT infrastructure.
| KL1508AIN-AXA-AE | KL1516AIN-AXA-AE | KL1108VN-AXA-AE | KL1116VN-AXA-AE | |
|---|---|---|---|---|
| KVM Ports | 8 x RJ-45 Female | 16 x RJ-45 Female | 8 x RJ-45 Female | 16 x RJ-45 Female |
| Maximum | 256 (via Daisy-chain) | 256 (via Daisy-chain) | 128 (via Cascade) | 256 (via Cascade) |
| LCD Module | 19″ TFT-LCD | 19″ TFT-LCD | 19″ | 19″ |
| Resolution | 1280 x 1024 @ 75 Hz | 1280 x 1024 @ 75Hz | 1280 x 1024 @75Hz | 1280 x 1024 @75Hz |
| Keyboard / Mouse | PS/2, USB, Serial | PS/2; USB | PS/2; USB | PS/2; USB |
| Port Selection | OSD, Hotkey, Pushbutton | OSD, Hotkey, Pushbutton | OSD, Hotkey, Pushbutton | OSD, Hotkey, Pushbutton |
| Response time | 5 ms | 5 ms | 5 ms | 5 ms |
| Action | Get a Quote Shop Now | Get a Quote Shop Now | Get a Quote Shop Now | Get a Quote Shop Now |
Integrated KVM console with 17", 19" LED-backlit LCD monitor
Dual Rail housing – LCD and keyboard/touchpad slide independently
Housing is slightly less than 1U with top and bottom clearance for smooth operation
LCD module rotates up to 120° for comfortable viewing
Exclusive LED illumination light for low-light visibility
Console lock secures the drawer when not in use
LCD power button helps save energy and extend display life
Space-saving RJ-45 ports with Cat 5e/6 cabling
High port density – up to 8 or 16 ports in 1U space
Optional rack-mount kits available
Control 8 or 16 servers directly; expandable to 128 / 256 servers through cascading
Extra console ports for external monitor, USB/PS/2 keyboard, and mouse
Supports PS/2, USB, Sun Legacy, Serial (RS-232) servers
Supports external USB mouse (HID devices)
Blade server support
Auto Scan mode for continuous monitoring
Broadcast Mode – send commands to all servers simultaneously (install software, shutdown, updates, etc.)
Multiple computer selection methods:
Front panel pushbuttons
Hotkeys
Multi-language OSD (On-Screen Display)
Models include one bus for remote KVM over IP access
Redundant LAN / Dual IP support with 10/100/1000 Mbps NICs
Advanced FPGA graphics processor for smooth, high-quality remote video
2× faster virtual media transmission speeds (on IP-enabled models)
High-grade security with TLS 1.3
FIPS 140-2 certified OpenSSL cryptographic module (Certificate #4282)
Two-level password security
Supports one administrator + up to 10 user accounts
Port-based access control to assign rights per server
Strong password protection to prevent unauthorized access
Superior local & remote video resolutions:
Up to 1920 × 1200 @ 60 Hz
1280 × 1024 @ 75 Hz on built-in LCD
Maximum distance up to 50 meters (depending on resolution)
24-bit color depth at the external console for clear visuals
Daisy-chain up to:
31 additional switches → control up to 256 servers
15 additional switches (on IP models) → up to 256 servers
Multiplatform support:
Windows
Mac
Linux
Sun
VT100-based Serial devices
KVM adapters automatically convert signal types — supports PS/2, USB, Sun, Serial systems without extra configuration
The Over IP LCD KVM Switch series brings together the KL1508Ai, KL1516Ai, KL1108V, and KL1116V models into a compact 1U dual-rail LCD console solution that delivers secure local and remote server access, high-density control for 8 or 16 servers with scalable cascading up to hundreds of devices, integrated LED-backlit monitoring and management, efficient space utilization, and reliable, disaster-ready centralized administration designed to meet the operational demands of modern datacenters, server rooms, and enterprise IT infrastructures.
