The Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Virtual Switching Framework (VSF) provides stacking scale and simplicity for enterprise edge, SMB and branch offices.
| JL261A | JL262A | |
|---|---|---|
| Model Name | Networking 2930F 24G PoE+ 4SFP Switch | Networking 2930F 48G PoE+ 4SFP Switch |
| I/O Ports | 24 RJ-45 10/100/1000 ports | 48 RJ-45 10/100/1000 ports |
| Weight | 3.9 kg | 4.46 kg |
| Dimension | 17.42x11.98x1.73 cm | 17.42x11.98x1.73 cm |
| Throughput | 41.7 Mpps | 77.4 Mpps |
| Switching Capacity | 56 Gbps | 104 Gbps |
| Power | 445 W | 459 W |
| Idle Power | 36.8 W | 48.6 W |
| Action | Get a Quote Shop Now | Get a Quote Shop Now |
Simple, secure, and scalable networking for modern businesses
Cost-effective switching with built-in uplinks and PoE+ for users,
access points, and IoT devices.
Dynamic Segmentation enforces consistent policies across wired and
wireless networks.
Centralized AI-driven network management through
HPE Aruba Networking Central.
Zero-Touch Provisioning enables quick setup of remote and
branch offices.
Supports cloud-based, on-premise, CLI, and Web GUI management
on the same hardware.
8-member VSF stacking allows easy expansion while keeping
switch management simple.
Up to 740W PoE to power access points, IP phones,
cameras, and IoT devices.
The HPE Aruba Networking 2930F Switch Series is designed for customers creating smart digital workplaces that are optimized for mobile users with an integrated wired and wireless approach. These convenient Layer 3 network switches include built in uplinks and PoE power and are simple to deploy and manage with advanced security and network management tools like HPE Aruba Networking ClearPass Policy Manager, and cloud based HPE Aruba Networking Central.
A powerful HPE Aruba Networking ProVision ASIC delivers performance, robust feature support, and value with programmability for the latest applications. Stacking with Virtual Switching Framework (VSF) provides simplicity and scalability. The 2930F supports built in 1GbE or 10GbE uplinks, PoE+, Access OSPF routing, Dynamic Segmentation, robust QoS, RIP routing, and IPv6 with no software licensing required
| Memory and processor: | Dual Core Arm Cortex A9 @ 1016 MHz, 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB 4.5 MB Ingress/7.875 MB Egress, 4 GB eMMC |
| Routing table size: | 2,000 IPv4, 1,000 IPv6 in hardware, 200 OSPF, 256 Static, 10,000 RIP |
| Switching capacity: | 104 Gbps , 56 Gbps |
| Dimensions: | 17.42 (w) x 9.7 (d) x 1.73 (h) in (44.25 x 24.63 x 4.39 cm) (1U height) |
| Weight: | 6.83 lb (3.10 kg) ,8.6 lb (3.9 kg), 9.83 lb (4.46 kg) |
| 1,000 Mb latency: | < 3.8 μs (64‑byte packets) |
| MAC address table size: | 32,768 entries |
| Operating temperature: | 32°F to 113°F (0°C to 45°C); up to 5,000 Feet, 0°C to 40°C (32°F to 104°F) up to 10,000 Feet |
| Operating relative humidity: | 15% to 95% @ 104°F (40°C), noncondensing |
| Non‑operating/storage temperature: | 15% to 95% @ 149°F (65°C) |
| Non‑operating/storage temperature: | 15% to 95% @ 149°F (65°C) |
| Acoustic: | Power: 54.1 dB, Pressure: 40.2 dB, Power: 55.7 dB, Pressure: 41.7 dB |
| Airflow direction: | Side‑to‑side |
| Frequency: | 50/60 Hz |
| Power efficiency certifications: | 80plus.org certification: Silver |
| Maximum heat dissipation: | 258.0 BTU/hr (272.2 kJ/hr) , 293.0 BTU/hr (309.1 kJ/hr) |
| Voltage: | 100–127/200–240 VAC, rated , 100–127/200–240 VAC, rated |
| PoE power: | 370W PoE+ |
| Routing: | Support for RIP routing and Access OSPF |
| Security: | 802.1X, MAC and Web Authentication, Source-port filtering, RADIUS/TACACS+, SSL, Port Security, and MAC address lockout |
| Network management: | Aruba ClearPass Policy Manager, Aruba AirWave, and Aruba Central |
| Virtual Switching Framework (VSF): | Virtualizes up to eight physical switches into one logical device |
| Software licensing: | No software licensing required |
