Processor:
|
11th Generation Intel Core i5-1135G7 (8 MB cache, 4 cores, 8 Threads, 2.40 GHz to 3.80 GHz, 28 W) -- 11th Generation Intel Core i5-1145G7 vPro (8 MB cache, 4 cores, 8 Threads, 2.60 GHz to 4.0 GHz, 28 W) -- 11th Generation Intel Core i7-1185G7 vPro (12 MB cache, 4 cores, 8 Threads, 3.0 GHz to 4.30 GHz, 28 W) |
|
Operating system:
|
Windows 11 Home, 64-bit -- Windows 11 Pro, 64-bit -- Ubuntu Linux 20.04 LTS, 64-bit |
|
Video Card:
|
Integrated: Intel Iris Xe Graphics |
|
Display:
|
13.3-inch, FHD, 1920 x 1080, 60 Hz, anti-glare, anti-reflection, anti-smudge, touch, 100% sRGB, 1400 nits, wide-viewing angle |
|
Memory:
|
8 GB, LPDDR4, 4266 MHz, integrated -- 16 GB, LPDDR4, 4266 MHz, integrated -- 32 GB, LPDDR4, 4266 MHz, integrated |
|
Storage:
|
M.2 2230, 128 GB, PCIe NVMe Gen3 x4, Class 35 SSD -- M.2 2230, 256 GB, PCIe NVMe Gen3 x4, Class 35 SSD -- M.2 2230, 512 GB, PCIe NVMe Gen3 x4, Class 35 SSD -- M.2 2230, 1 TB, PCIe NVMe Gen3 x4, Class 35 SSD -- M.2 2280, 256 GB, PCIe NVMe Gen4 x4, Class 40 SSD -- M.2 2280, 512 GB, PCIe NVMe Gen4 x4, Class 40 SSD -- M.2 2280, 1 TB, PCIe NVMe Gen4 x4, Class 40 SSD -- M.2 2280, 2 TB, PCIe NVMe Gen4 x4, Class 40 SSD -- M.2 2280, 512 GB, PCIe NVMe Gen4 x4, Class 40 SSD, self-encrypting -- drive |
|
Ports:
|
1 RJ45 Ethernet port, 1 USB 3.2 Gen 1 port, 1 USB 3.2 Gen 1 port with PowerShare, 1 TBT4/USB 3.2 Gen 2 Type-C port with PowerDelivery 3.0, 1 TBT4/USB 3.2 Gen 2 Type-C port with PowerDelivery 3.0 (optional), 1 HDMI 2.0 port, 1 Serial RS-232 port, 1 headset (headphone and microphone combo) port, 1 Optional I/O bay (Choose from: RJ-45/USB Type-A/Native Serial/Fischer USB 3.0 9-pin/Blank) |
|
Slots:
|
1 microSD-card slot, 1 Nano SIM card slot, 1 Smart card reader slot (optional), 1 kensington lock slot, 1 Express card slot (optional) |
|
Dimensions & Weight:
|
Height: 36.50 mm, Width: 324.00 mm, Depth: 220.00 mm, Weight (minimum): 2.32 kg, Weight (maximum): 2.33 kg |
|
Camera:
|
No camera/No microphone -- 720p at 30 fps, HD RGB camera (optional) -- 1080p at 30 fps, FHD RGB/IR camera (optional) |
|
Audio and Speakers:
|
Stereo speakers with Waves MaxxAudio Pro, 2 W x 2 = 4 W total (Realtek ALC3254) |
|
Chassis:
|
3K Carbon fiber with plastic resin and TPE (Thermoplastic Elastomer). Base material is Magnesium. |
|
Wireless:
|
Wireless: Intel AX210, 2x2, 802.11ax -- Qualcomm WCN6856, 2x2, 802.11ax, MU-MIMO, Bluetooth wireless card *** Mobile broadband: Qualcomm SDX20 4G LTE, Up to 1.2 Gbps, 5x20 MHz -- Discrete U-BLOX GPS (optional) |
